• H.264 real-time high compression, support dual stream network transmission
• Stand-alone Linux2.6 operation system
• Graphics & Windows OSD interface
• Support CIF recording resolution
• ADPCM audio compression
• Support triplex operation: record, playback, net transmission
• Support to operate with USB mouse
• Support remote view with Mobile Phone
• Support to backup & upgrade with USB flash disk
• Support to real-time remote view with IE (WindowsXP/Vista Support)
• Support to transmit audio via network
• Support PTZ control via built-in RS-485 port
• Selectable packing time for recording files
• VGA output

8-CH Digital Video Recorder Description   Video Compression H.264 Video System NTSC / PAL Operation System Linux Video Input / Output BNC 8-channel inputs / 2-channel outputs Audio Compression 8kHz*16bit ADPCM Audio Input / Output RCA 1-channel input / 1-channel output Display Frame Rate PAL: 200fps / NTSC: 240fps Playback Resolution PAL: CIF(352x288) / NTSC: CIF(352x240) Total Recording Frame Rate PAL: 200fps@CIF / NTSC: 240fps@CIF Recording Mode Always / schedule / motion detection / sensor triggered Recording Pack Time 15/30/45/60mins selectable HDD Interface Support SATA HDD & USB disk Network Interface RJ45, 10M/100M Network Protocol Support TCP/IP, UDP, DHCP, DNNS, PPPoE Network Function Support to live view with IE (Internet Explorer) & with Mobile phone USB2.0 USB mouse, USB disk (backup, upgrade) Playback Mode Normal play, fast forward, fast rewind, frame by frame Backup Backup AVI file via USB flash disk, USB disk, USB CD/DVD-RW & Network PTZ Control Built-in RS485, support PELCO-P & PELCO-D Alarm Mode Motion Detection, Sensor triggered, video loss, HDD error, HDD full Senor & Alarm I/O 8 sensor inputs / 1 alarm output Power Supply DC 12V/3A (power adaptor included) Power Consumption 10~15W Working Temperature -10°C to +40°C Working Humidity 10% to 90% Dimension 300 x 220 x 47mm (W x D x H)
